Standard Equipment
74 HP Deutz Turbo Diesel Engine
- 44” carbide tooth slasher saw
- Splitter force 34-ton
- Dual joystick controls with auto split
- 7-way hydraulic repeater wedge or 8-way hydraulic adjustable star wedge
- 16′ infeed
- 3-leg hydraulic folding live deck
- Hydraulic log stop adjustable 12-24″ length
- Operator safety cage with deluxe seat
- Automatic clamping
- Fuel Capacity: 30-gallon fuel tank
- Hydraulic Reservoir Capacity: 80 US gallons
- Hydraulic Oil Cooler: 35,000 BTU/hr
- 12k lbs tandem axles with electric brakes and running lights
- 2 5/16″ ball hitch or pintle hitch (your choice)
Performance
Production Rate: up to 6 full cords/hr
- Cycle Time (cut & split): every 2 to 5 seconds
- Maximum Log Diameter: 20”
- Maximum Log Length: 30’ (butt on the deck)
- Estimated Fuel Consumption: 1.5 – 2 GPH
- Weight: 11,850 lbs. with integrated conveyor
- Transport Dimensions: 8’-0” wide, 23′-0″ long, 12′-8″ high
Optional Equipment
42-ton splitter
- Extended infeed conveyor to 20′
- 4-, 6-, 8-, 12- or 16-way hydraulic adjustable splitting wedges
- Extra live deck legs, dual drive available
- Trap doors for last piece assist with endcut bypass
- Heated operators cab
- Air conditioning with insulation package
- 24′ to 40′ stand alone offloading conveyor
- 12′ or 16′ integrated offloading conveyor
- Overhead log grapple assist (crooked wood)
- Available with tractor PTO-Drive
- Available with a 3-phase electric motor option
